Overview

ASEPCONNECT™ inline connector

ASEPCO close couple connectors are for connecting flush-mounted probes and instruments to process lines. They are easier to install and clean than the alternatives, and have ASEPCO's patented aseptic seal, which is based on the same reliable seal that you find in our valves.

Features and benefits

Patented sealing face improves gasket sealing edge to eliminate leakage
Clean, aseptic design for use in critical aseptic processing applications
Easy to place, seal, and inspect, thereby lowering maintenance costs
Seamless design eliminates dead legs and joint leakage
Monel studs prevent galling during maintenance
Clearance slots for use with rupture disks
Optional integrated valve allows for easy sterilisation

Technical summary

Mounting type	Flush
Connection	Tri-clamp component connection
Surface finish options	Electropolished, Max 10 micro-inch Ra (0.25 µm Ra), Max 15 micro-inch Ra (0.375 µm Ra), Max 20 micro-inch Ra (0.5 µm Ra)
Certification and compliance	ISO 9001
Standards	ASME BPE, CE-PED

Technical Summary table lists features available within the range. See ‘Specifications’ tab for model specific information.

Specifications

Technical specifications

	ASEPCONNECT inline
Mounting type	Flush
Sizes	1.0", 1.5", 2.0"
Connection	Tri-clamp component connection
Operating temperature range	-80 °C to 200 °C
Operating temperature range	-112 °F to 392 °F
Operating gauge pressure range	-1 barg to 7 barg
Operating gauge pressure range	-14.5 psig to 101.5 psig
Surface finish options	Electropolished, Max 10 micro-inch Ra (0.25 µm Ra), Max 15 micro-inch Ra (0.375 µm Ra), Max 20 micro-inch Ra (0.5 µm Ra)
Certification and compliance	ISO 9001
Standards	ASME BPE, CE-PED
Weight	1.81 - 2.36 kg
Weight	4 - 5.2 lbs

(Maximum working pressure is determined by the design pressure of the gasket being used in the assembly.)

ASEPCONNECT inline dimensions

Size	A	B	C	D
inches	mm (in)	mm (in)	mm (in)	mm (in)
1.50	41.7 (1.64)	156.2 (6.15)	12.7 (0.50)	34.8 (1.37)
2.00	54.1 (2.13)	168.9 (6.65)	12.7 (0.50)	47.5 (1.87)

Size	Weirless Size	A	B	C	D
inches	inches	mm (in)	mm (in)	mm (in)	mm (in)
1.50	0.50	41.7 (1.64)	156.2 (6.15)	12.7 (0.50)	34.8 (1.37)
2.00	0.50	54.1 (2.13)	168.9 (6.65)	12.7 (0.50)	47.5 (1.87)
1.50	0.75	41.7 (1.64)	156.2 (6.15)	19.1 (0.75)	34.8 (1.37)
2.00	0.75	54.1 (2.13)	168.9 (6.65)	19.1 (0.75)	47.5 (1.87)

Materials of construction

Material

Hastelloy C22, Hastelloy C276, Stainless steel 316L, Stainless steel AL-6XN

Control

Weights

Size	ASEPCONNECT Inline AIXX-0001	ASEPCONNECT Inline AIXX-0002	ASEPCONNECT Inline AIXX-0003
inches	Kg (lb)	Kg (lb)	Kg (lb)
1.50	1.81 (4.0)	1.77 (3.9)	2.09 (4.6)
2.00	2.36 (5.2)	2.18 (4.8)	2.54 (5.6)

Literature

Datasheet

ASEPCONNECT Inline datasheet (EN).pdf
PDF - 964,4kb

Order Information

Product codes

Product number	Product description
AI10-0006-2	Asepconnect assembly 1" Inline mount fits 0.75" line weld-end connection 316L/EN 1.4435 15 Ra mechanical Includes clamps
AI10-0007-2	Asepconnect assembly 1" Inline mount fits DN15 (DIN32676 Range A) line weld-end connection 316L/EN 1.4435 15 Ra mechanical Includes clamps
AI15-0001-01	Asepconnect assembly 1.5", Inline mount fits 0.5" line clamp-end connection 316L/EN 1.4435 20 Ra mechanical Includes clamps
AI15-0401-01	Asepconnect assembly 1.5", Inline mount fits 0.5" line weld-end connection 316L/EN 1.4435 20 Ra microinch finish, electropolished & passivated Includes clamps
